| Kit Contents
|
How it works
The system works by radiating ultrasonic beams covering the area infront of the vehicle. The beams are reflected by obstructions ahead, and re-enter the sensors. The reflected beam information is processed to calculate the distance of the obstruction.
When the vehicle is less than 1.5 metres from the obstruction the audible alert will emit intermittent bleeps. As the vehicle gets closer to the obstruction the frequency of the bleeps increases. At 30 centimetres from the obstruction the bleeps become a continuous solid tone.
| Stage | Distance | Awareness | Alarm |
| 1 | 200 - 160cm | Safe Mode | No |
| 2 | 150 - 100cm | Safe Mode | Bi----Bi----Bi |
| 3 | 90 - 50cm | Alarm Mode | Bi--Bi--Bi |
| 4 | 40 - 30cm | Danger Mode | Bi-Bi-B |
| 5 | 30 - 0cm | Stop | Bi---------- |
|
| NEW "Swap Socket" Feature All of our kits now come with the new watertight swap socket feature based 6 inches from the sensor heads, it makes installation quicker and easier. Also should you ever have a problems with faulty sensors or accident damage in the future it facilitates easy replacement without having to remove the bumper again and rewire from scratch. |
Optional Wedges
This system comes with optional angled wedges, giving greater flexibility according to the shape of your bumper. The wedges can be used if your bumper is slightly angled up - or downwards, to ensure the sensor's signal is still sent out parallel with the road's surface.
 |  |  |
| Technical Specification
|  |
| Some Useful Measurement Information (measurements are approximate and not guaranteed) | |
| Component | Dimensions |
| Size of Buzzer | 40mm Diameter, 20mm Thick |
| Size of Processor | L96mm x W68mm x H26mm |
| Size of Ultrasonic Recess Sensors | Head Width 25mm x Sensor Depth 22mm |
| Diameter Size For Drilling | 21mm (Drill Bit Supplied) |
| Length of Sensors Cabling | 6m |
| Length of Cabling for Buzzer | 2m |
Maintenance
No routine maintenance or adjustment is required. Dirt, frost or snow accumulated on the sensors may cause the system to activate incorrectly. Clean carefully with a soft cloth. Do not use chemicals or spirits. Applying hot water in frozen conditions may damage the sensors. The sensors can be washed carefully with warm soapy water
